Semi Automatic Rotary Bottle Washing Machine Manufacturer And Supplier In Ghana

Semi Automatic Rotary Bottle Washing Machine

A Semi Automatic Rotary Bottle Washing Machine is an essential piece of equipment for pharmaceutical, food, cosmetic, and chemical manufacturers in Ghana who require reliable and thorough cleaning of bottles before filling. This machine is particularly suitable for facilities with lower to medium production output, where flexibility, process control, and cost efficiency are key operational priorities.

Technogen Enterprise is an experienced manufacturer, supplier, and exporter of semi automatic rotary bottle washing machines, offering compact and highly efficient solutions engineered to meet the cleaning standards of regulated industries in Ghana. The machine is designed to wash both glass and plastic bottles, ensuring effective removal of dust, particles, and residues from internal and external bottle surfaces.

Designed for Low to Medium Output Production Lines in Ghana

Many pharmaceutical and allied manufacturers in Ghana operate production lines that do not require fully automatic washing systems but still demand high-quality cleaning performance. This semi automatic rotary bottle washing machine is specifically designed to address these needs.

The machine operates on a rotary intermittent motion driven by a Geneva mechanism. Bottles are manually loaded and unloaded into dedicated pockets by the operator, while the washing cycles are executed automatically. This configuration provides precise control over the washing process while keeping capital and operating costs optimized.

Rotary Intermittent Motion with Geneva Mechanism

The heart of the machine is its Geneva drive-based bottle indexing system, which ensures accurate positioning of bottles at each washing station. This intermittent rotary motion allows consistent exposure of bottles to washing and air cycles, ensuring repeatable and effective cleaning results.

The controlled movement minimizes bottle handling stress and reduces the risk of bottle damage, making it suitable for fragile glass containers commonly used in pharmaceutical and injectable applications.

Washing Process and Sequence

The semi automatic rotary bottle washing machine is designed to clean both internal and external surfaces of bottles using a combination of water and air washing cycles. The washing sequence can be customized based on product requirements and regulatory expectations.

The standard washing sequence includes:

• Fresh water wash – first stage

• Hot detergent wash – second stage

• Fresh water wash – third stage

• DM or DI water wash – fourth stage

• External bottle wash

• Air blow for effective drying

This multi-stage process ensures thorough cleaning and removal of contaminants prior to filling operations.

Salient Features

• Bottle indexing system based on Geneva drive mechanism

• Suitable for round and flat bottles

• Smooth and easy operation

• Four internal washes, one external wash, and one air wash

• Customized washing sequence as per application

• Stationary nozzles to avoid water contamination and bottle neck chipping

• High-pressure spray nozzles for effective cleaning

• Easy manual loading and unloading with two-row arrangement

• Individual solenoid valve for each washing sequence

• High-capacity centrifugal pumps for washing larger bottles

• Pumps and tanks mounted on portable stand for easy maintenance

• Optional water recycling arrangement based on customer requirement

Hygienic Design and Construction

The machine is constructed using high-quality materials suitable for pharmaceutical and food-grade applications. Stationary nozzles ensure consistent washing performance while preventing cross-contamination between washing cycles.

The portable pump and tank assembly simplifies cleaning, inspection, and maintenance, making the machine well-suited for facilities in Ghana where operational uptime and ease of servicing are critical.

Operator-Friendly Configuration

Manual loading and unloading allow operators to visually verify bottles before and after washing, adding an additional layer of quality assurance. The ergonomic design and smooth rotary motion help maintain consistent throughput while reducing operator fatigue.

The machine can accommodate a wide range of bottle sizes without complex format change parts, enabling quick changeovers between products.

Applications Across Industries in Ghana

Pharmaceutical Industry
Used for washing bottles prior to liquid filling, syrups, suspensions, and injectable preparations.

Food and Beverage Industry
Suitable for cleaning bottles used for sauces, syrups, and liquid food products.

Cosmetics and Personal Care
Ensures clean containers for lotions, shampoos, and cosmetic liquids.

Chemical and Allied Industries
Used for pre-filling washing of chemical and specialty liquid containers.

Washing Sequence Overview

Technical Specifications

Advantages for Manufacturers in Ghana

• Ideal for low and medium production volumes

• Effective internal and external bottle cleaning

• Simple operation with controlled automation

• Reduced water consumption with optional recycling

• Low maintenance and long service life

• Easy integration with filling and capping lines

Pharmaceutical and allied manufacturers seeking a dependable semi automatic rotary bottle washing machine manufacturer and supplier in Ghana benefit from equipment that balances efficiency, hygiene, and operational flexibility. This machine supports consistent bottle cleanliness, improved product quality, and compliance with industry standards, making it a practical solution for facilities aiming to strengthen their primary packaging operations while maintaining cost control and process reliability.
