Servo-Based Shrink Sleeve Labeling for Modern Ghanaian Packaging Lines
In competitive consumer markets, shelf impact and label accuracy directly influence brand perception. The Servo Automatic Shrink Sleeve Labeling Machine developed by Technogen Enterprise is engineered to deliver precise, high-speed, and waste-controlled sleeve application for manufacturers in Ghana.
Designed to meet the requirements of fast-moving consumer goods, beverages, food, personal care, and chemical sectors, this machine supports full-body sleeves, neck sleeves, and tamper-evident applications. With scalable output capacities and advanced servo control, it integrates seamlessly into packaging lines operating in Ghana’s industrial hubs such as Accra, Tema, Kumasi, and Takoradi.
Modular Engineering with Servo Precision
The shrink sleeve labeling machine is built on a modular architecture that simplifies maintenance and enhances operational reliability. A high-performance servo-driven sleeve dispensing system ensures consistent sleeve placement, even at higher speeds, while the advanced PLC–HMI interface allows operators to fine-tune parameters with ease.
The machine is designed to process a wide range of sleeve materials including PVC, PET, OPS, and PLA, providing manufacturers in Ghana the flexibility to select materials aligned with branding goals and sustainability initiatives.
No Bottle – No Sleeve for Material Savings
A standout operational advantage is the No Bottle – No Sleeve logic. This intelligent feature ensures sleeves are dispensed only when a container is present, eliminating wastage of premium sleeve material and reducing operating costs. The system is particularly valuable for high-speed lines where even minor inefficiencies can translate into significant material loss.
Static charge abolition technology further improves sleeve placement accuracy, preventing misalignment and ensuring clean, wrinkle-free application across diverse container shapes.
Built for Speed, Stability, and Versatility
Depending on the selected model, the shrink sleeve labeling machine can deliver production speeds from 100 to 300 bottles per minute. The high-speed rotary cutter ensures precise sleeve cutting, while the bottle separating and positioning assemblies maintain stable container flow.
The variable-speed slat chain conveyor—manufactured from Delrin or AISI 304 stainless steel—supports smooth transport of glass, PET, HDPE, and other container materials. Sensor-less variable frequency drive control enables seamless synchronization with upstream fillers and downstream shrink tunnels.
Hygienic Construction and Industrial Durability
Manufactured using top-quality AISI 304 stainless steel sheets and advanced fabrication technology, the machine offers excellent corrosion resistance, structural rigidity, and ease of cleaning. This construction supports CGMP-aligned operations and makes the equipment suitable for food and beverage environments common in Ghana.
Imported gear motors and gearboxes ensure long service life and stable torque delivery, contributing to maintenance-free operation and consistent performance across multi-shift production schedules.
Salient Features
CGMP-compliant modular design
Machine frame fabricated from AISI 304 stainless steel
No container – no sleeve system to prevent material wastage
Advanced servo-based sleeve dispensing unit
Static charge abolition for accurate sleeve placement
High-speed rotary cutter mechanism
PLC–HMI control for intuitive operation
Variable-speed slat chain conveyor (Delrin / AISI 304)
Sensor-less VFD speed control
Imported gear motor and gearbox
Suitable for glass, PET, HDPE containers
Compatible with varied container shapes including plastic, tin, and corrugated containers
Maintenance-free operation
Technical Specifications
| Parameter | TGSSL-125 | TGSSL-225 | TGSSL-325 |
|---|
| Output per Minute | Up to 100 | Up to 200 | Up to 300 |
| Container Size | Ø 28 mm to Ø 125 mm, height up to 320 mm | | |
| Sleeve Length | 30 mm to 250 mm | | |
| Sleeve Thickness | 0.035 mm to 0.75 mm | | |
| Label Material | PVC, PET, OPS, PLA | | |
| Sleeve Roll Inner Diameter | ≥ 4 in (101.6 mm) | | |
| Sleeve Roll Outer Diameter | 400 mm | | |
| Conveyor Height | 860–910 mm | | |
| Electrical Rating | 1.5–2 kW, 380 V AC, 50/60 Hz, 3 Phase | | |
| Change Parts | Center pillar, worm, cutter | | |
Applications Across Ghana’s Manufacturing Sectors
The Servo Automatic Shrink Sleeve Labeling Machine is widely adopted in Ghana for:
Beverage bottling including water, soft drinks, and juices
FMCG and food product packaging
Personal care and cosmetic containers
Edible oil and lubricant bottles
Chemical and household product packaging
Its ability to handle full-body, neck, and tamper-evident sleeves makes it a versatile solution for brand-driven packaging strategies.
A Dependable Manufacturer and Supplier for Ghana
Technogen Enterprise is globally recognized as a manufacturer and supplier of advanced labeling and packaging machinery. With servo-driven accuracy, modular construction, and intelligent material-saving features, the shrink sleeve labeling machine delivers measurable value for Ghana-based manufacturers seeking higher throughput and consistent label quality.
The equipment’s scalability, compatibility with multiple sleeve materials, and robust stainless steel construction make it a future-ready investment for businesses focused on efficiency, presentation, and long-term operational reliability.
